$0.98The Story
Pneumatic connectors are commonly used with 3D printers to connect Bowden tubes to extruders and hot ends, providing a reliable, strong fitting with little to no movement of the tube once fitted.
This is a pack of five KJH-04-M6 pneumatic connectors which accept Bowden tubes with a 4mm outer dimension (4mm OD) and 2mm inner dimension (2mm ID), such as the tubes we sell in the store.
We sell a number of other styles of pneumatic connectors - take a look in our 3D printing section for more!
Specifications
- Type: KJH-04-M6
- Thread OD: 5.9mm
- Height: 18.8mm
- Nut OD: 8mm
- Thread length: ~3.9mm
- Input diameter (thread end): 2.8mm
- Compatible PTFE: 4mm OD / 2mm ID
- Weight (per connector): 2.5g
Package Contents
- 5x KJH-04-M6 (Black) pneumatic connectors
