M-Bus HAT for Raspberry Pi v2.0

With this M-Bus HAT for Raspberry Pi, you can extend your Raspberry Pi with functions for smart metering! The HAT provides an M-Bus master to which other M-Bus devices such as electricity, water or gas meters (with the appropriate interface) can be connected directly.

A datasheet/user guide is available to help you get started. With libmbus, powerful C++ software is available for the Raspberry Pi, which can be used with the M-Bus HAT. If you prefer Python take a look at the pyMeterBus project.

Features

• M-Bus (Meter-Bus) Master
• Compatible with European standard EN 13757-2
• For the remote reading of consumption meters
• For up to 6 unit-loads (9mA)
• Power supply by Raspberry Pi or external DC power supply (9-30V)
• Galvanically isolated interface
• Removable screw terminals for bus and power supply connection
• Indicator LEDs for RX and TX signals
• Selectable UART via jumper (with Raspberry Pi 4/5 only)
• For Raspberry Pi 2 / 3 / 4 / 5, Raspberry Pi Zero and compatible SBC

Resources

• With libmbus, powerful C++ software is available for the Raspberry Pi, which can be used with the M-Bus HAT.
• If you prefer Python take a look at the pyMeterBus project.
• V2.0 Datasheet
• M-Bus homepage

Package Contents

• 1x M-Bus HAT (standard version)
• 1x Terminal block connector
• Shorting headers

Raspberry Pi not included

Revision History

• As of 23/04/2025 we are stocking v2.0
