SparkFun DE9 Breakout - Female

The SparkFun Female DE9 Breakout includes a female DE9 connector with all nine pins and two ground connections routed to a 0.1" PTH header, measuring 31.75mm x 22.86mm with two 4-40 mounting holes.

---

The SparkFun Female DE9 Breakout is a simple breakout board featuring a female DE9 (commonly referred to as DB9) connector. The board comes with the female DE9 connector and breaks all nine pins, along with two extra ground connections to a 0.1in.-spaced plated through-hole (PTH) header.

This breakout measures 31.75mm x 22.86mm and has two mounting holes that fit a 4-40 screw.

Features

• Female DE9/DB9 Connector
• 0.1in. Plated Through-Hole PTH Pins
• 2x Mounting Holes

Specifications

• Board measures 31.75mm x 22.86mm

Resources

• Schematic
• KiCad Files
• Board Dimensions

Package Contents

• 1x SparkFun DE9 Breakout - Female
