Stackable Serial Expansion HAT [Discontinued]

The Serial Expansion HAT expands the functionality and capabilities of the Raspberry Pi, giving you an I2C interface & 2-channel UART with 8 programmable GPIO Pins.

The HAT includes 8 programmable GPIO pins via I2C in which you can attach more accessories and add-ons, and the board is stackable up to 16 layers, allowing up to 32-channels UART! The onboard LEDs also help you to identify the UART working status.

Features

• Standard Raspberry Pi 40-pin GPIO header
• Onboard SC161S752: expands 2-channel UART and 8 programmable GPIO through I2C - no extra pins required
• Stackable up to 16 modules by setting the address jumper (up to 32-ch UART)
• Onboard LEDs for indicating the UART working status
• Reserved 12C control pins: allows the board to work with other control boards
• GitHub resources

Resources

• Product GitHub

Specifications

• Operating voltage: 3.3V
• Expansion chip: SC161S752
• Control interlace: 12C
• Dimensions: 65mm x 30mm

Note: Raspberry Pi not included
